2026 Wire Saw Machine For Granite

The 2026 wire saw machine from Kaida Stone Machinery is designed for block separation and trimming in granite and marble quarries. It is commonly used for horizontal and vertical cutting when extracting large stone blocks from quarry benches. Equipped with a powerful drive system and advanced control technology, the machine is capable of performing horizontal, vertical, inclined, and other directional cuts in granite, marble, and other natural stone quarries.

By using a diamond wire loop driven by the main flywheel, the machine separates the stone along a pre-drilled cutting line. This method helps reduce edge breakage and allows quarry operators to recover larger and more regular blocks. The small cutting gap reduces raw material waste and improves overall production efficiency.

The machine uses a PLC-based control system combined with frequency converters to regulate wire speed and cutting current. During operation, the system adjusts the travelling speed of the machine according to the cutting load. This ensures stable performance and keeps the diamond wire operating under optimal cutting conditions at all times.

The machine also features multiple protection functions, including wire break detection, overload protection, cutting completion protection, and fault alarms, ensuring safe and reliable operation in quarry environments.

During operation, the machine automatically adjusts the wire tension and cutting current through the PLC control system. This helps maintain stable cutting speed and reduces excessive wear on the diamond beads.

Intelligent Cutting Process
The cutting process is automatically adjusted according to the load condition, improving cutting efficiency and extending the service life of the diamond wire.

Motor-Driven Cutting Head
The movement and rotation of the cutting head are driven by motors equipped with position limit protection, ensuring safe and accurate positioning.

Real-Time Digital Display
Important operating parameters such as cutting current, wire speed, machine travel speed, and cutting time are clearly displayed on the control panel.

Comprehensive Safety Protection
The machine is equipped with protection systems for wire breakage, machine overload, cutting completion, and other abnormal conditions.

Lower Operating Cost

Compared with traditional flame cutting methods, the operating cost of diamond wire saw cutting can be reduced to only 10%–40%, making it a more economical quarrying solution.

In most granite quarries, the cutting depth can reach around 10 to 20 meters depending on the wire length and drilling layout. This makes the wire saw suitable for separating large blocks from the quarry bench.

Wider Application Range

The machine is suitable for granite, marble, limestone, and sandstone quarries, and can operate effectively even in complex geological conditions.

Better Block Quality

Diamond wire cutting produces smooth cutting surfaces and regular blocks, minimizing damage to the stone and improving block yield.

Safer and Cleaner Operation

The wire saw cutting method produces less dust, lower noise, and fewer vibrations, creating a safer and more environmentally friendly working environment.

Operating equipment in a quarry environment requires strict safety management. In quarry operations, operators usually install the machine along the drilled cutting line. Proper wire tension and guide pulley alignment are important to maintain stable cutting.

Stable Wire Tension Control
The PLC control system automatically adjusts the wire tension and cutting current to keep the diamond wire running under optimal conditions, reducing the risk of wire breakage.

Automatic Fault Detection
The machine continuously monitors operating conditions. If abnormal situations occur, such as wire breakage, overload, or abnormal cutting resistance, the system will automatically stop the machine and trigger an alarm.

Position Limit Protection
The cutting head movement and rotation are equipped with limit protection devices to prevent overtravel and ensure safe positioning during operation.

Low Dust and Low Vibration Operation
Compared with traditional quarry cutting methods, the diamond wire saw produces significantly less vibration and dust, which improves the working environment and reduces operational risks.

Operator Safety Measures
Operators are recommended to maintain a safe distance during operation and follow standard quarry safety procedures. Clear operational indicators and digital displays help operators monitor the cutting process in real time.

Kaida provides technical assistance for machine installation, operation training, and maintenance. Our engineers can help customers troubleshoot operational issues through remote communication.

Technical Guidance and Training
We provide operation guidance and technical support to help customers understand the installation, operation, and maintenance of the wire saw machine.

Remote Technical Assistance
Our technical team can provide remote troubleshooting support through video calls, photos, and technical communication to quickly identify and solve operational issues.

Spare Parts Supply
Kaida maintains a supply of essential spare parts to ensure fast replacement and reduce machine downtime when maintenance is required.

Maintenance Support
We provide maintenance recommendations and service guidance to help customers maintain machine performance and extend the service life of key components.

Long-Term Cooperation
With more than 20 years of experience in stone machinery manufacturing, Kaida Stone Machinery continues to support customers worldwide with reliable products and professional service.

1. What types of stone can the wire saw machine cut?

The machine can be used in granite, marble, limestone, and sandstone quarries. The cutting performance depends on stone hardness, wire quality, and operating conditions.

2. What cutting directions are possible with the wire saw machine?

The machine supports horizontal, vertical, and inclined cutting in quarry operations. This flexibility allows quarry operators to extract blocks more efficiently and adapt to different quarry structures.

3. What is the maximum cutting depth of a diamond wire saw?

Depending on the quarry conditions and wire length, the cutting depth can typically reach 10–20 meters. This allows the extraction of large and regular stone blocks with high productivity.

4. Is the wire saw machine difficult to operate?

No. The machine is designed with an automatic PLC control system and digital monitoring panel, which makes operation simple and intuitive. Most operators can learn basic operation after short training.
