Automatic Stone Surface Flaming Machine
Product Overview
The KDHS-650/1250 Automatic Stone Surface Flaming Machine is a heavy-duty, highly automated processing solution designed by Fujian Province Kaida Stone Machinery Co., Ltd. for precise heat-treating and surface texturing of natural stones (primarily granite).
By utilizing an automated continuous conveyor feed system paired with high-temperature gas burner nozzles, the KDHS series produces a uniform, slip-resistant, natural flamed surface ("flamed finish") on granite slabs, tiles, pavers, and outdoor cladding stones. Designed to replace labor-intensive manual flaming torches, this machine significantly boosts daily output, ensures consistent quality, reduces gas consumption, and improves worker safety.
Whether processing standard 650 mm paving strips or wide 1250 mm gang-saw slabs, the KDHS-650/1250 provides stone fabricators and processors with an ideal balance of speed, stability, and operating economy.
technical data
| Parameter / Model | KDHS-650 | KDHS-1250 |
| Max. Processing Width | 650 mm | 1250 mm |
| Processing Thickness Range | 10 mm – 60 mm (Customizable) | 10 mm – 60 mm (Customizable) |
| Conveyor Speed | 0 – 6 m/min (Frequency Inverter Adjustable) | 0 – 6 m/min (Frequency Inverter Adjustable) |
| Fuel / Gas Compatibility | LPG / Propane / Natural Gas + Oxygen | LPG / Propane / Natural Gas + Oxygen |
| Cooling Method | Synchronized Water Jet Cooling | Synchronized Water Jet Cooling |
| Main Transmission Power | 1.5 kW – 2.2 kW | 2.2 kW – 3.0 kW |
| Water Consumption | ~1.5 – 2.5 m³/h | ~2.5 – 4.0 m³/h |
| Operation Mode | Automatic Continuous Feed | Automatic Continuous Feed |
| Overall Dimensions (L×W×H) | Approx. 6500 × 1400 × 1600 mm | Approx. 7500 × 2000 × 1600 mm |
| Approximate Weight | ~2,500 kg | ~3,800 kg |
(Note: Custom dimensions, double-burner configurations, and automated slab loading/unloading roller tables can be tailored upon request.)
Products details
Key Features & Benefits
Continuous Automated Conveyor System
Equipped with a heavy-duty, heat-resistant conveyor belt system with variable frequency speed control (VFD). Workers simply load raw cut slabs on one end and collect fully flamed, water-cooled slabs on the other.
Uniform & Anti-Thermal Shock Flame Control Engineered burner nozzles deliver a steady, flat flame strip across the entire slab width. Integrated micro-adjustable burner angles and heights ensure even flame distribution without warping or cracking high-density granite.
Advanced Fuel & Energy Efficiency
Optimized gas-air mixture manifold supports LPG (Liquefied Petroleum Gas), Propane, or Natural Gas combined with Oxygen. Designed to reduce gas consumption by up to 15–20% compared to traditional manual or semi-automatic flame guns.
Integrated Water Cooling & Dust Suppression System Incorporates synchronized high-pressure water cooling spray nozzles immediately after the flame station. This rapidly cools the heated stone, stabilizes thermal stress, and suppresses airborne quartz dust for an eco-friendly working environment.
Rugged Heavy-Duty Structure
Built with high-rigidity steel framework and anti-corrosion protective coatings to withstand high thermal radiation, moisture, and continuous heavy industrial operations.
User-Friendly Control Panel & Safety Protection
Features an intuitive control interface with emergency stop protection, automatic flame failure detection, gas pressure sensors, and easy adjustment of belt speed and flame temperature.
our company
If you have another questions,please feel free to contact us.
