Automatic Stone Polishing Machine For Artificial Quartz Granite Stone Slab

Automatic Stone Polishing Machine For Artificial Quartz Granite Stone Slab

Fully-auto Polishing Machine This machine is the right choice to increase daily production and decrease cost. Introduction: 1. Applicable for polishing the surface of granite slabs and tiles. 2. Automatic polishing machine which absorbs the most advanced technology of granite polishing and has...
Send Inquiry
Product Introduction

Fully-auto Polishing Machine

This machine is the right choice to increase daily production and decrease cost.

Introduction:
1. Applicable for polishing the surface of granite slabs and tiles.
2. Automatic polishing machine  which absorbs the most advanced technology of granite polishing and has created
several patent technologies.
3. Superior material, reasonable structure, completed processing technique, stable performance, high efficiency and
energy saving.
4. Electric parts are of worldwide brand, PLC control system and friendly human-machine interface via LCD to achieve
fully auto computerized control.
5. Automatically detect the slab profile by laser scanning device.
6. Sensitive collision avoidance of polishing head.

Technical Parameters

Model

12 Heads
16 Heads
20 Heads
No. of polishing heads
pc
12
16
20
Max. polishing width
mm
500-1250 mm (others upon request)
Polishing thickness
mm
15-50
15-50
15-50
Conveyor Speed
m/min
0-2.6 m/min
0-2.6 m/min
0-2.6 m/min
Main motor power
kw
105 KW
135 KW
162 KW
Overall dimensions (L x W x H)
mm
6600 x 2200 x 2200
7900 x 2200 x 2200
9200 x 2200 x 2200
Water consumption
m³/h
13
18
22
Total weight
T
13
16
20
Polishing efficiency

210-270sqft/h
270-320sqft/h
300-350sqft/h
