Product Introduction
Product Introduction
Structural characteristics
❈ bridge structure, one beam is located on the left and right longitudinal rails, equipped with an independent workbench.
❈ the cutting saw blade is installed in the spindle box, which is installed in the intermediate box. The intermediate box is connected by four guide columns. The four guide columns move up and down in the intermediate box through the hydraulic system, and the intermediate box is fixed on the beam and moves left and right. In the intermediate box, the intermediate box is connected with four guide columns, the four guide columns move up and down in the intermediate box through the hydraulic system, and the intermediate box is fixed on the cross beam and moves left and right.
❈ the left and right groups of gears installed on the beam realize the front and rear displacement of the beam through the tooth rows on the two longitudinal rails.
❈ the worktable is installed independently, and the hydraulic control worktable rotates horizontally by 90 ° or 360 ° and vertically by 0 ° ~ 85 °.
❈ the head adopts double cylinder hydraulic lifting and four guide rail structure. The left and right travel of the saw blade and the front and rear travel of the beam are controlled by servo motor and driver.
❈ the guide post lifting is equipped with grease fittings.
❈ infrared knife setting is adopted.
Product Details
1. Enhanced Cutting Efficiency: The Marble Bridge Cutting Machine's design allows for quick and efficient cutting, increasing productivity and reducing processing time.
2. High Precision: With advanced positioning and measurement tools, the Marble Bridge Cutting Machine delivers high-precision cuts, minimizing material waste.
3. Excellent Surface Quality: The cutting process results in smooth and flat surfaces, often reducing the need for secondary finishing.
Factory Pictures
Company Advantages
Firstly, we has more than 20 years of stone machinery manufacturing experience, brand influence, wide coverage.
Secondly, we support the delivery of engineers to overseas customer factories for on-site installation and training.
Thirdly, equipped with R & D department to support customized product development in time according to customer needs.
Fourthtly, we are manufacturer, you could get best price without paying any commission.
FAQ
1
Q: How long is the warranty period for machine?
A: one year !
2
Q: When can you ship my order?
A: Normally 15-20days after advanced payment is received. The exact delivery date will be advised after order is confirmed. We will deliver it as soon as possible if you need them urgently.
3
Q: How to request machine?
A: You just need to tell us your requirements, our professional sales and technical team will recommend the most suitable machines for you.
4
Q: About price?
A: As a supplier, we guarantee that you can get the best price and service.
5
Q: About customization?
A: ODM/OEM business partner will be warmly welcome.
Technical Data
Appellation
Unit
SZQJ-400
SZQJ-600
SZQJ-700
SZQJ-800
Max. processing size(L×W×H)
mm
3200×3200×70
3200×3200×180
3200×3200×220
3200×3200×280
Diameter of blade
mm
φ350-φ400
φ400-φ600
φ400-φ700
φ400-φ800
Dimensions of worktable(L×W)
mm
3200×2000
3200×2000
3200×2000
3200×2000
Worktable tilting degree
N°
0-85
0-85
0-85
0-85
Worktable rotating degree
N°
90/360
90/360
90/360
90/360
Main motor power
kw
15
15
15/18.5
15/18.5
Water consumption
m³/h
4
4
4
4
Overall dimensions(L×W×H)
mm
6000×5000×2800
6000×5000×2800
6000×5000×2800
6000×5000×2800
