Horizontal Stone Chamfering & Polishing Machine
The Horizontal Stone Chamfering & Polishing Machine WSDJ-4C is specially designed for automatic 45° back chamfering and polishing of granite, marble, and sintered stone slabs.
Adopting a horizontal belt feeding structure, this machine is widely used for edge processing of kitchen countertops, stair treads, threshold stones, and other stone products. The feeding speed can be adjusted according to different materials, while the chamfering width and angle can be precisely controlled.
With a combination of rough grinding and fine grinding processes, the machine ensures smooth and uniform chamfering results with less chipping. It is an ideal solution for high-efficiency mass production and can be integrated into automatic stone slab processing lines.
Main Features
Horizontal belt feeding structure ensures stable and continuous slab transportation
Automatic 45° chamfering and polishing for granite, marble, and sintered stone
Adjustable feeding speed suitable for different stone materials
Adjustable chamfering width and angle according to production requirements
Combined rough grinding and fine grinding process provides smooth and uniform edges
High-strength welded steel frame with annealing treatment for excellent stability
Variable frequency speed control system improves processing efficiency and precision
Suitable for mass production and automatic stone processing lines
Technical Data
| Item | Unit | WSDJ-4C |
|---|---|---|
| Number of Processing Heads | pcs | 4 |
| Motor Power of 1# Saw Blade | kW | 7.5 |
| Motor Power of 2#-3# Bevel Grinding Heads | kW | 3 |
| Motor Power of 4# Grinding Head | kW | 3 |
| Conveyor Structure | 250mm wide belt + high elasticity silicone rubber pressure belt | |
| Thickness Adjustment of Press Beam | Electric lifting adjustment | |
| Main Drive System | 3kW variable frequency speed control motor reducer | |
| Number of Conveyor Belts | pcs | 2 |
| Number of Saw Blades | pcs | 2 |
| Number of Bevel Grinding Wheels | pcs | 2 |
| Saw Blade Diameter | mm | Ø180-Ø300 |
| Bevel Grinding Wheel Diameter | mm | Ø150 |
| Voltage | V/Hz | 380/50 |
| Minimum Processing Width | mm | 30 |
| Maximum Processing Thickness | mm | 35 |
| Working Speed | m/min | 1-3 |
| Total Power | kW | 18 |
| Approximate Weight | T | 2.5 |
| Overall Dimension (L×W×H) | mm | 4500×1300×2200 |
Application
The Horizontal Stone Chamfering & Polishing Machine is widely used in:
Granite processing factories
Marble processing plants
Sintered stone production lines
Kitchen countertop factories
Stair tread and threshold stone processing workshops
Automatic stone slab edge processing lines
It is mainly used for 45° back chamfering, edge grinding, and polishing of stone slabs, providing high-quality finishing results for large-scale production.
If you have any questions, please feel free to contact us.
