Fully Automatic Stone Flaming Line
Inconsistent surface textures, high labor overhead, and slow processing speeds are the primary operational bottlenecks in traditional manual stone flaming. The KDHS-800 Stone Automatic Flaming Machine changes this dynamic entirely through a fully continuous, automated line that mechanizes both stone slab conveying and torch travel. Driven by smart variable-frequency controls, the system dynamically synchronizes mechanical feed rates with multi-nozzle sweeping speeds to achieve an perfectly uniform, premium textured topography on every square meter.
Engineered for fabrication plants transitioning to high-efficiency, cleaner stone processing, the KDHS-800 provides multi-gas versatility. Operators can seamlessly configure the manifold for methane, acetylene, or natural gas depending on regional market pricing. With an aggressive throughput exceeding 65 square meters per hour, this system slashes manual grinding room overhead while instantly expanding your plant's production scale.
Key Features
- Continuous Line Automation – Eliminates manual torching errors by combining automated vertical slab tracking with smooth horizontal cross-travel mechanics, reducing labor costs to a bare minimum.
-
- Unmatched Texture Uniformity – VFD speed parameters guarantee stable, repeatable results across large batches, completely removing human variances like scorch pits, deep scarring, or skipped spots.
- Heavy-Duty 8-Nozzle Torch Array – Equipped with an optimized 8-piece high-velocity burner manifold, ensuring deep, balanced thermal coverage across the full 800mm maximum processing width.
- Adaptable Fuel Intake – The machine's heavy-duty internal valving easily adapts to diverse gas choices-including methane, acetylene, LPG, and natural gas-giving you the leverage to manage utility expenses locally.
- High-Efficiency Power Footprint – Maintains a high production capacity of 60 to 80 m²/h on a highly economical 3 kW motor configuration, maximizing throughput without driving up factory power bills.
Technical Data
| Parameter Item | Unit | Specification (KDHS-800) |
|---|---|---|
| Number of Burning Heads | pcs | 8 |
| Processing Width | mm | 800 |
| Output (Capacity) | m²/h | 60 - 80 |
| Motor Power | kw | 3 |
| Maximum Processing Height | mm | 100 |
| Voltage | V | 380 |
| Weight | kg | 1000 |
| Overall Dimensions (L×W×H) | mm | 4000 × 1450 × 1500 |
Applications & Finished Surface Styles
- Anti-Slip Pedestrian Surface Work: Specifically built for heavy-duty texturing of exterior granite paving, public plazas, commercial steps, urban curbs, and custom architectural thermal cladding where safety and precision are critical.
Why Partner With Us
Our Manufacturing Edge & Global Support
• Over 20 Years of Machinery Expertise: We have spent more than two decades refining stone-processing hardware. Our brand represents rugged durability, proven structural design, and heavy-duty components that easily survive harsh, wet stone factory environments.
• Direct Overseas Engineering & Commissioning: We do more than just ship containers. Our field technicians travel globally directly to your workshop floor to manage structural alignment, system gas calibration, and operator safety training to hit full production on day one.
• In-House R&D for Custom Configurations: Material hardness and production line space differ in every quarry region. Our dedicated technical department handles customized machine adaptations quickly, adjusting widths and PLC options to seamlessly integrate with your existing equipment layout.
Frequently Asked Questions
Q: Can we customize the PLC touchscreen interface language for our local staff?
A: Absolutely. While our standard firmware includes standard English and Chinese dual-language interfaces, we regularly configure and pre-install other regional languages, including Russian, Arabic, Polish, Spanish, and Korean, to match your production team's requirements.
Q: How do you verify the stability of the gas manifolds and automated systems prior to export?
A: Quality control is rigorously executed at every station. Each automated flaming machine goes through multiple inspection tiers covering electrical limits, pressure sealing, and drive mechanics. Before final crating, we complete real trial cycles under load and provide you with detailed high-definition video checkouts of your machine running at peak speed.
Q: What happens if our engineering team runs into gas pressure or pipeline adjustment issues during installation?
A: We accommodate whatever strategy suits your workflow. For maximum assurance, we can send field support engineers straight to your site to coordinate mechanical integration and fuel-line setups. If your factory handles self-guided setup, we supply precise foundation blueprint files, explicit gas-flow schematics, and instructional media for instant remote onboarding.
