5+1 Axis CNC Stone Cutting Machine
Products Description
Unveiling the latest addition to our advanced machinery lineup – the 5+1 Axis CNC Stone Cutting Machin. This high-precision cutting tool is the epitome of innovation, offering unparalleled performance and versatility in the world of CNC machining.
Product Detail
Technical product specifications can be found at the end of the page.
Company information
Technical data
|
Appellation |
Project |
Unit |
CNC-600 |
|
The machine stroke |
X axis stroke |
mm |
3400 |
|
Y axis stroke |
mm |
2200 |
|
|
Z axis stroke |
mm |
500 |
|
|
A axis stroke |
N° |
0-90 (Automatic) |
|
|
C axis stroke |
N° |
±361 |
|
|
Cutting thickness |
mm |
0-180 |
|
|
General configuration |
Fast running speed |
m/min |
25 |
|
Spindle power |
kw |
15-22 |
|
|
Spindle speed |
rpm |
0-4000 |
|
|
Saw blade diameter |
mm |
350-600 |
|
|
Platform size |
mm |
3200×2000 |
|
|
Tilt degree |
N° |
0-85 |
|
|
The total power |
kw |
≈ 33 |
|
|
The total weight |
kg |
≈ 7000 |
|
|
Equipment dimensions |
mm |
6000×3300×5000 |
|
|
Functional configuration |
Camera function |
- |
√ |
|
Blade measurement function |
- |
(Optional) | |
|
Suction cup function |
- |
(Optional) |
|
|
Milling cutter function |
- |
(Optional) |
