Horizontal Block Stone Cutting Machine
Introducing the Horizontal Blade Block Cutting Machine QSDQ-1600, a high-performance stone cutting solution specially designed for granite and marble block processing. With advanced horizontal blade technology, this machine can directly cut the bottom part of slabs, eliminating manual unloading operations and significantly improving production efficiency.
High Efficiency, Precision Cutting: The QSDQ-1600 adopts a PLC control system, human-machine interface (HMI), and high-precision magnetic ruler to ensure accurate cutting positioning. The inverter-controlled feeding system allows operators to adjust the cutting speed according to different stone materials, achieving better cutting performance and higher productivity.
Stable Structure, Reliable Performance: The machine is equipped with a hydraulic lifting system and high-precision screw nut transmission system, ensuring smooth movement, excellent cutting accuracy, and stable operation. The horizontal blade adopts a hydraulic driving system combined with a guide structure, making the whole machine more reasonable and durable.
technical data
| Item | Unit | QSDQ-1600 |
|---|---|---|
| Crossbeam Length | mm | 7500 |
| Diameter of Vertical Blade | mm | 1600 |
| Maximum Cutting Size | mm | 3000×2200 |
| Maximum Vertical Travel | mm | 1400 |
| Main Motor Power | kW | 90 |
| Diameter of Horizontal Blade | mm | 400-600 |
| Horizontal Cutting Column Stroke | mm | 650 |
| Horizontal Blade Motor Power | kW | 18.5 |
| Overall Dimensions | mm | 7500×4000×7000 |
| Water Consumption | m³/h | 10 |
Products details
our company
Applications:
Stone Block Processing: Ideal for granite and marble processing factories that require efficient block cutting and slab production with high precision.
Large Stone Fabrication: Suitable for large-scale stone production lines, improving cutting efficiency and reducing manual handling during slab processing.
Quarry and Stone Industry: Widely used in stone quarries and fabrication plants for processing large stone blocks into high-quality slabs.
Invest in Quality: By choosing the QSDQ-1600 Horizontal Blade Block Cutting Machine, you are investing in safer operation, higher productivity, and reliable stone processing performance.
If you have any questions, please feel free to contact us.
