Gantry Profile Cutting Machine

Kaida mechanical profiling machine is a common stone equipment in stone special-shaped processing. It is suitable for the processing of special-shaped stone such as arc line and Roman column. The profiler is divided into a single arm type and a gantry type. The operating system has PLC...

Send InquiryChat Now
Product Details

Kaida mechanical profiling machine is a common stone equipment in stone special-shaped processing. It is suitable for the processing of special-shaped stone such as arc line and Roman column.


The profiler is divided into a single arm type and a gantry type.

The operating system has PLC programmable control, and CNC computer-controlled, to meet the different customers requirements.

The single-arm profiling machine has a small body and does not occupy space, and is suitable for processing stones with smaller specifications. The workbench uses oil-immersed sealing rails.

Double-knife design, Durable , high cutting efficiency, good stability and easy operation, ,.

The gantry or profiling machine adopts the gantry-type beam structure, which is more stable. The large-size workbench is more suitable for large-scale stone processing, and can be used for lifting columns. It also adopts oil-immersed sealing guide table, double-knife design, more efficient and more stable.


The PLC programmable control system is automatically tracked by the fiber optic probe, and the model of the curved (straight) line model is automatically profiled by a diamond saw blade into a stone craft product such as a curved (straight) line shape. Up and down lifting and left and right passes are automatically controlled by the program, and the worktable adopts frequency converter speed control. It can be adjusted according to the material of the stone, and can also realize the processing of the arc-shaped line, with high automation, high cutting precision, double knife design, high cutting efficiency and good stability. Simple to operate, especially suitable for lines, arc-shaped lines, Roman columns. Processing of special-shaped stone such as large circular arc plate,

The CNC computer control system uses computer control, CAD input graphics, and can also use the USB to automatically generate the curved (straight) line shape of the stone to be cut. Compared with the PLC infrared copying machine, it saves the trouble of making templates, is easy to learn, convenient and flexible, and is more convenient for stone shaped processing, shortens working time and increases the economic efficiency of the enterprise.


Appellation

Unit

DNFX-3000

Max.cutting length

mm

3000

Max.cutting wideth

mm

1600

Max.cutting thickness

mm

500

Diameter of blade

mm/min

350-600

Main motor power

Kw

15

Water consumption

m³/h

4
